ViewSonic IFP7553-ED-M 75" 4K Android EDLA ViewBoard Interactive Display
Couldn't load pickup availability
The ViewSonic IFP7553-ED-M 75-inch 4K interactive display is built for modern collaboration, combining a secure Android EDLA platform with seamless Google and Microsoft 365 integration. Its 40-point infrared touch surface with Write-Away technology allows multiple users to annotate instantly with styluses or fingers, while the IPS panel delivers wide 178° viewing angles and 450 cd/m² brightness for clear visibility in any room.
An integrated 52W front-facing soundbar with a 20W subwoofer and an eight-microphone beamforming array with noise cancellation ensures crystal-clear audio and voice pickup up to 26 feet away. The octa-core processor with 8GB RAM and 128GB storage handles multitasking smoothly, and extensive connectivity includes four HDMI 2.1 inputs, four USB-C ports, DisplayPort, and an Intel OPS slot.
IT teams benefit from centralized management via ViewSonic Manager, Google Workspace Enterprise Management, and Microsoft Intune, while built-in security features like data encryption and two-way authentication protect sensitive information. The display meets EPEAT, ENERGY STAR 8.0, and RoHS standards, supporting sustainability goals without compromising performance.
Key Features
| Brand | ViewSonic |
| Model Number | IFP7553-ED-M |
| Display Size | 75" |
| Resolution | 3840 x 2160 (4K UHD) |
| Panel Type | IPS |
| Touch Technology | Infrared |
| Touch Points | 40 (Windows), 20 (Android) |
| Brightness | 450 cd/m² |
| Aspect Ratio | 16:9 |
| Refresh Rate | 60Hz |
| Response Time | 8ms |
| Contrast Ratio (Dynamic) | 5,000:1 |
| Contrast Ratio (Static) | 1,200:1 |
| Viewing Angles | 178° horizontal, 178° vertical |
| Backlight Life | 50,000 hours |
| Panel Surface | Anti-Glare, Anti-Fingerprint (7H Mohs) |
| Operating System | ViewBoard OS EDLA (Android) |
| Processor | Quad-core |
| Memory | 8GB LPDDR |
| Storage | 128GB eMMC |
| Internal Speakers | 16W x2 + 20W Subwoofer (52W Total) |
| Microphone | 8-Array Beamforming with Noise Cancellation |
| HDMI 2.1 Inputs | 4 |
| HDMI Output | 1 |
| DisplayPort | 1 |
| VGA | 1 |
| USB Type-A | 5 |
| USB Type-B | 3 |
| USB Type-C | 4 |
| Ethernet LAN (RJ45) | 2 |
| Intel OPS Slot | 1 (80-pin) |
| RS232 | 1 |
| SPDIF | 1 |
| Line In | 1 |
| Mic In | 1 |
| Wi-Fi | VB-WIFI-005 Adapter Included |
| Bluetooth | 5.2 |
| NFC | Yes |
| VESA Mount | 800 x 400 mm |
| Voltage | 100-240 VAC |
| Typical Power Consumption | 102W |
| Standby Power | <0.5W |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Operating Humidity | 20-80% (non-condensing) |
| Physical Dimensions (W x H x D) | 67.21 x 41.7 x 4.66 in |
| Packaging Dimensions (W x H x D) | 74.8 x 45.67 x 8.46 in |
| Net Weight | 113.98 lbs |
| Gross Weight | 140.87 lbs |
| Certifications | CTUVus, FCC, ENERGY STAR 8.0, EPEAT, CEC, RoHS |
| TAA Compliant | Yes |
| Warranty | 3-Year Limited On-Site (Parts, Labor, Backlight) |
Highlights
- Robust Security and Centralized Management
- Seamless Integration with Google and Microsoft
- Enhanced Engagement with ViewSonic® Software
- Easy Access with Quick User Authentication
- Incredible Writing Experience
- Immersive Audio for Maximum Engagement
- High-Performance Multitasking
- Seamless Android Experience with Backward Compatibility
- Eco-Friendly & Energy Efficient
Warranty
3-year limited warranty on parts, labor and backlight, onsite warrantyWhat's included
- IFP7553
- Power Cord (3m)
- USB-C Cable
- Remote control
- USB Touch Cable (3m)
- Stylus x 2
- Quick Start Guide + Compliance statement
- RS232 adapter
- Clamp x 5
- Camera Plate
- Screw x 8 (camera 2+2, wall mount 4)
- HDMI cable 3m
- VB-WIFI-005 WiFi Adapter
Downloads
- Datasheet
- IFP7553-ED-M User Guide (English)
- IFP7553-ED-M User Guide (Spanish)
- IFP7553-ED-M User Guide (Traditional Chinese)
