Sharp PN-LB753 75" UHD Collaboration Display
Couldn't load pickup availability
The Sharp PN-LB753 AQUOS BOARD is an interactive 75-inch 4K Ultra HD collaboration display designed for modern meeting rooms and educational environments. Featuring direct-lit LED technology with 3840 x 2160 resolution, 500 cd/m² maximum brightness, and a 1,500:1 contrast ratio, it delivers clear visuals and wide 178-degree viewing angles across medium-to-large spaces.
Equipped with 40-point IR multi-touch capability and Android OS 14 SoC, this EDLA-certified display provides integrated access to Google applications, enterprise tools, and eShare wireless casting. Users can present directly via built-in software or connect seamlessly through multiple digital inputs, including three HDMI ports and a feature-rich USB-C connection supporting DisplayPort Alt Mode and up to 100W power delivery.
Built for flexible integration, the display includes an integrated 15W per channel stereo sound system, an OPS expansion slot for optional PC modules, and full LAN and RS-232C external control compatibility. Convection cooling ensures quiet, fanless operation, supported by durable commercial construction and standard 800 x 400 mm VESA mounting.
Key Features
| Brand | Sharp Electronics Corporation |
| Model Number | PN-LB753 |
| Screen Size | 75" |
| Native Resolution | 3840 x 2160 |
| Panel Technology | TFT LCD |
| Backlight Type | LED Direct-lit |
| Touch Technology | 40-Point IR Multi-touch |
| Brightness (Maximum) | 500 cd/m² |
| Brightness (Typical) | 450 cd/m² |
| Contrast Ratio | 1500:1 |
| Viewing Angle | 178° / 178° |
| Refresh Rate | 60Hz |
| Operating System | Android OS 14 |
| Audio Output | 15W + 15W Stereo |
| Digital Inputs | 3 x HDMI, 1 x USB Type-C |
| Data Ports | 2 x USB 3.2 Gen1 Type-A, 1 x USB 3.2 Gen1 Type-C, 2 x USB 2.0 Type-A, 1 x Touch USB 2.0 Type-B |
| Control Ports | 1 x RS-232C, 2 x LAN (RJ-45) |
| Dimensions (W x H x D) | 67.2" x 33.9" x 3.4" |
| Net Weight | 105.8 lbs. |
| Shipping Weight | 130.1 lbs. |
| VESA Mount Pattern | 800 x 400 mm |
| Warranty | 5-Year Limited |
Highlights
- 75" Class (74.5” diagonal) Screen Size
- Brilliant Ultra-HD (3,840 x 2,160) Direct Lit LCD Display
- 40–Point IR Multi-touch
- EDLA Certified
- eShare Wireless Casting
- 500 cd/m2 Brightness; 1,500:1 Contrast Ratio
- Android OS 14 SoC Arm® Cortex®A73x4 2.3Ghz+Arm®
- Built-in 15W per Channel Stereo Audio System
- 5-Year Limited Warranty
Compatibility
- Simply NUC OPS-SNi5RWP OPS PC
- Shuttle PN-SPCi7W11A signage PC
- Shuttle PN-SPCi5W11A signage PC
- Peerless-AV PN-SR898 rolling cart
- Airserver ASC300 Universal Screen Mirror Solution
- EverPro EP31605SH 5 Meter USB Type C cable
Warranty
5 years
What's included
- AC power cord:1
- Remote control unit:1
- Remote control unit battery (AAA size) : 2
- Wireless Adapter
- Wireless Adapter anti-theft cover
- Setup manual:1
- Blank sticker(cover SHARP logo):1
- Cable clamp:3
- Camera mount
- STB mount
- USB cable:1
- Touch pen:2
Downloads
- PN-ZCMS1 Application Notes
- PN-ZCMS1 Warranty
- Specification Brochure: PN-LB653 / PN-LB753 / PN-LB863
- AirServer Connect 3 Specification Brochure
- EP316-05SH EverPro 5 Meter USB Type C Cable Specifications
- PN-SPCi5W11A Intel® Alder Lake-S® Core® Specifications
- PN-SPCi7W11A Intel® Alder Lake-S® Core® Specifications
- OPS-SNi5RWP SimplyNUC OPS Computing Module Specifications
- Sharp AQUOS BOARD® Interactive Displays What’s the Difference?
- PN-ZCMS1 Operation Manual
