Pure Resonance Audio DA2240 2-Channel Power Amplifier Dual-Impedance 70V 240W
Regular price
$699.99
Couldn't load pickup availability
Frequently Asked Questions
What is the difference between an audio amplifier and a power amplifier?
A power amplifier is the stage that provides the wattage needed to drive speakers, while the broader term audio amplifier can refer to several devices in the signal chain, including preamps, mixers with amplification, or integrated amplifiers. In commercial audio, this distinction matters because a power amplifier is what determines how many speakers you can run and whether the system supports 70V distributed audio or low-impedance speaker loads.
The Pure Resonance Audio DA2240 is specifically a 2-channel power amplifier. It is designed to take a line-level audio signal through balanced inputs and deliver up to 240 watts per channel. Its standout feature is dual-impedance operation, so each channel can be set independently for 70V distributed systems or 4 to 16 ohm speakers.
This type of amplifier is best for installers, facilities, and businesses building a retail, office, industrial, or paging system. If you need tone controls, source switching, or microphone mixing, those functions usually come from other components, not the power amplifier itself.
What is the best power amplifier for a commercial sound system?
The best power amplifier for a commercial sound system is one that matches the speaker type, coverage method, and duty cycle of the installation. For many businesses, the key decision is whether the system uses 70V distributed audio, low-impedance speakers, or both. A strong commercial choice should also offer reliable protection, balanced inputs, clear status monitoring, and efficient cooling for long operating hours.
The Pure Resonance Audio DA2240 is a good fit when flexibility is a priority because each of its two channels can run independently at either 70V or 4 to 16 ohms. That means one amplifier can support a distributed speaker zone and a conventional low-impedance zone at the same time. It also delivers 240 watts per channel, uses a compact 1U rack-mount chassis, and includes short-circuit, overload, and overheating protection.
This model is especially useful for contractors and facilities that want one amplifier for mixed commercial applications. The main tradeoff is that its frequency response is tailored for commercial audio, not full-range audiophile listening.
What should I look for when choosing a professional power amplifier?
When choosing a professional power amplifier, start with four basics: output power, speaker compatibility, installation format, and protection features. You want enough wattage for your speakers, support for the correct impedance type, a chassis that fits your rack or equipment space, and safeguards for continuous use.
For commercial installations, voltage type is especially important. Many business audio systems use 70V distributed lines for multiple ceiling or wall speakers, while others use 4, 8, or 16 ohm speakers in smaller zones. The Pure Resonance Audio DA2240 stands out because each of its two channels can be switched independently between 70V and 4 to 16 ohms. That gives installers more design flexibility than amplifiers locked into a single output format.
Other practical features include balanced inputs, detachable Euroblock terminals, front-panel level controls, LED indicators for signal and protection, and fan cooling. This amplifier is best for users who want commercial reliability and mixed-system flexibility. If you need very wide-band music performance, you may want to compare frequency-response requirements first.
Is a 70V amplifier better than a low-impedance amplifier for commercial audio?
Neither is universally better. A 70V amplifier is usually better for distributed commercial audio with many speakers spread across a building, while a low-impedance amplifier is often better for shorter cable runs and smaller groups of speakers where maximum speaker-level control is needed.
A 70V system simplifies wiring and makes it easier to add multiple speakers in offices, retail stores, schools, or warehouses. Low-impedance outputs such as 4 to 16 ohms are common when driving conventional speakers directly in a more localized area. The Pure Resonance Audio DA2240 is useful because it does not force you to choose one approach for the entire amplifier. Each 240-watt channel can be set independently to 70V or 4 to 16 ohms.
That makes it a strong option for mixed-use spaces, such as a business that needs ceiling speakers for background music in one zone and standard speakers in another. The main consideration is proper system design, since speaker tap settings and load calculations still need to be matched correctly.
Can one amplifier power both 70V speakers and standard 4 ohm or 8 ohm speakers?
Yes, but only if the amplifier is designed for that kind of flexibility. Many amplifiers support either 70V or low-impedance operation, but not both independently on separate channels. If you need to run distributed speakers in one area and conventional speakers in another, you need a model with per-channel output selection.
The Pure Resonance Audio DA2240 was built for exactly that scenario. It is a dual-impedance 2-channel amplifier, and each channel can be switched independently to either 70V or 4 to 16 ohms. That allows a contractor to power a distributed audio system and a low-impedance speaker zone from the same 1U rack-mounted amplifier.
This is especially helpful in retail, office, hospitality, or industrial environments where different zones have different speaker requirements. The tradeoff is that installers still need to calculate speaker loads carefully and avoid mixing unmatched loads on the same output. It is flexible, but it still requires proper commercial audio planning.
How much amplifier power do I need for a commercial audio system?
The amount of amplifier power you need depends on the number of speakers, their wattage or tap settings, the size of the space, and how loud the system needs to play. In a 70V system, installers usually total the watt taps of all speakers on a channel and leave headroom above that number. In a low-impedance system, they match amplifier output to speaker power handling and impedance.
The Pure Resonance Audio DA2240 provides 240 watts per channel, which makes it suitable for many small to mid-sized commercial zones. In 70V mode, each channel can support a distributed speaker load up to 240 watts. In low-impedance mode, it is rated at 240 watts at 4 ohms and 120 watts at 8 ohms.
This output level works well for background music, paging, and general-purpose zone audio in offices, retail spaces, and similar facilities. If your project includes very large spaces or high-SPL requirements, you may need additional amplifier channels or a higher-powered large-venue solution.
What makes the Pure Resonance Audio DA2240 a good choice for commercial installations?
The DA2240 is a strong commercial installation choice because it combines flexible output options, rack efficiency, and built-in protection in a straightforward 2-channel design. Its most important feature is dual-impedance operation, which lets each channel run independently at either 70V or 4 to 16 ohms. That can reduce the need for separate amplifiers in mixed-speaker environments.
From an installation standpoint, it uses a compact 1U 19-inch chassis, balanced inputs, and detachable Euroblock terminals, all of which suit professional rack builds. It also includes front-panel volume controls and LED indicators for signal, clipping, and protection status, which helps with setup and troubleshooting.
For long-term reliability, it uses a Class-D design with an internal switching power supply rated at 85% efficiency, plus automatic cooling fans and protection against short-circuit, overload, and overheating. This amplifier is best for offices, retail stores, industrial facilities, and other commercial settings. Its main limitation is that it is optimized for commercial voice and music distribution rather than high-end full-range entertainment audio.
Is a Class-D amplifier good for continuous business or facility use?
Yes, Class-D amplifiers are often an excellent choice for continuous business and facility use because they are efficient, generate less heat than many traditional designs, and can deliver substantial output from a compact chassis. Those advantages matter in commercial racks where space, ventilation, and power efficiency all affect long-term reliability.
The Pure Resonance Audio DA2240 uses a Class-D design with an internal switching power supply that reaches about 85% efficiency. That helps reduce wasted energy and heat buildup during long operating hours. It also includes fan-forced cooling and a heat-dissipation layout intended to keep the amplifier at a stable operating temperature over extended use.
This makes it a practical option for background music, paging, and zone audio in retail, office, and industrial applications. As with any forced-air amplifier, installers should still allow for proper rack ventilation. If absolute silent operation is required in a noise-sensitive room, fan-cooled designs may need placement in an equipment rack away from listeners.
What inputs and controls should I expect on a professional commercial power amplifier?
A professional commercial power amplifier should provide secure, installer-friendly connections and basic front-panel monitoring. The most useful features typically include balanced inputs for cleaner signal transmission over longer runs, detachable terminals for permanent installations, independent channel level controls, and status indicators that make troubleshooting easier.
The Pure Resonance Audio DA2240 covers these essentials well. Both channels use balanced inputs and detachable Euroblock terminals, which are common in commercial audio systems because they provide a stable connection and simplify structured wiring. On the front panel, it has independent volume knobs for each channel and LED indicators for signal presence, peak clipping, and protection status.
These features benefit contractors, integrators, and facilities teams that need a simple amplifier to configure and monitor in a rack. The limitation is that this is a power amplifier, not a mixer amplifier, so users looking for built-in source selection, microphone paging controls, or DSP will likely need additional upstream equipment.
What are the main tradeoffs to consider before buying the Pure Resonance Audio DA2240?
The main tradeoff is that the DA2240 is designed for practical commercial audio flexibility rather than all-in-one signal processing or full-range hi-fi performance. That is not a drawback for most business installations, but it is important to understand before buying.
On the positive side, it offers two independently selectable 240-watt channels that can run either 70V or 4 to 16 ohms, which is unusually useful for mixed commercial zones. It also fits in a 1U rack space, includes balanced inputs and Euroblock terminals, and has built-in protection against overheating, overload, and short circuits. Its Class-D design and fan cooling support efficient long-term operation.
The considerations are that its frequency response is 80Hz to 16kHz, which is well suited to paging, background music, and general commercial sound, but not ideal if you need deep bass or extended high-frequency detail for premium music playback. It also does not include mixing, DSP, or source management, so those functions may require separate components.
The Pure Resonance Audio DA2240 is a professional 2-channel Class-D power amplifier designed for versatile commercial audio applications. This high-performance unit features a unique dual-impedance design, allowing each 240-watt channel to operate independently at either 70V or 4-16 ohms via selectable output switches. This flexibility enables contractors to power a distributed audio system and low-impedance speakers simultaneously from a single rack-mounted device.
Engineered for reliability in demanding environments, the DA2240 is housed in a compact 1U 19-inch industrial chassis that minimizes rack space while maximizing output. The internal switching power supply achieves 85% efficiency, significantly reducing power loss and heat generation. Integrated automatic cooling fans and a strategic heat dissipation layout ensure the amplifier maintains a stable operating temperature even during continuous long-term use.
Safety and monitoring are prioritized with comprehensive protection circuitry against short-circuits, overloading, and overheating. The front panel provides intuitive control with independent volume knobs and clear LED indicators for signal, peak clipping, and protection status. Both channels utilize balanced inputs and detachable Euroblock terminals for secure, professional installations in retail, office, or industrial settings.
| Rated Power Output | 2 x 240W at 70V, 240W at 4 Ohm, 120W at 8 Ohm |
| Speaker Outputs | 70V / 4-16Ω |
| Frequency Response | 80Hz - 16kHz (+1 dB, -3 dB) |
| Signal to Noise Ratio | ≥95 dB |
| Total Harmonic Distortion | ≤0.1% (at 1kHz, 1/3 rated power) |
| Protection Circuitry | High temperature, overload, short-circuit |
| Cooling System | Fan-forced cooling |
| Power Consumption | 600W |
| Dimensions (H x W x D) | 1.73" x 19" x 12.4" |
| Weight | 10.36 lbs |
| UPC | 810093051229 |
